Diagnostics and Controls

No: 1 | Low [10KB, 250x187] | High [2.3 MB, 1502x1127]

The Compton Polarimeter at ELSA (Bonn).

No: 2 | Low [7KB, 250x172] | High [168KB, 1361x938]

Principle of the Optical Replica technique: an optical image of the electron charge distribution is generated. A corresponding system has been installed at FLASH.
